Agilent 5977A GC/MS with 7890B GC and 7693A Autosampler

This set includes:

• (1) Agilent 7890B
• (1) Agilent 5977A with diffusion pump
• (1) Agilent G4513A Autoinjector
• (1) Agilent G4514A 7693A Autosampler with 150 position Tray
• (1) Edwards Rotary Vane Pump RV5
• Mass Hunter Data Software

Agilent 7890B GC

• Retention Time Locking (RTL) maintains exact retention times from injection to injection, column to column, instrument to instrument, and lab to lab
• Capillary Flow Technology (CFT) provides unique instrument capabilities, such as multi-dimension gas chromatography (GC-GC/Deans Switch), comprehensive two-dimension gas chromatography (GCxGC) with flow modulation, and backflush at the beginning, middle, or end of the analytical column
• Single filament TCD that does not require a separate reference gas, does not require manual potentiometer adjustment, and provides a stable baseline with a minimal amount of signal drift
• Auto-ranging FID provides the ability to detect and quantitate from parts per billion (ppb) to parts per thousand in a single injection
• Integrated SCD/NCD (sulfur or nitrogen chemiluminescence detector) provides low ppb detection, equi-molar response, and quantitation for sulfur or nitrogen contaminants without quenching from matrix
• Carrier Gas Options: Helium Conservation Module, Hydrogen Sensors and Alternate Carrier Gas Solutions dramatically reduce the amount of helium used to offer flexibility in your laboratory
• Large Valve Oven (LVO) allows for the combination of multiple methods and simplified maintenance
• Multimode inlet (MMI) serves as a programmable temperature vaporizing injector with flexible capabilities
• Agilent Inert Flow Path provides increased sensitivity for active compounds, from injection to detection
• Low Thermal Mass (LTM) modules, up to 4 installed and operating, increase sample throughput with rapid column heating and cooling

Agilent 5977A GC/MS

• Extractor Ion Source
  • The ‘push-pull’ principle of the Extractor Ion Source delivers more ions to the mass analyzer and increases confidence of your trace analysis methods.
• Instrument Detection Limit (IDL)
  • Replace signal-to-noise ratio (S/N) with the new industry standard that measures the true sensitivity of your mass spec instrument.
• Heated Gold Quadrupole
  • The quartz, hyperbolic monolithic is the only mass filter that can be heated to 200°C without loss of resolution or mass accuracy.
• Triple-Axis Detector (TAD)
  • Optimizes signal-to-noise by combining efficient ion collection and amplification with the elimination of neutral noise.
• GCMSD MassHunter with MSD ChemStation Data Analysis
  • Supports the MassHunter data analysis workflow for all instruments and the classic MSD ChemStation workflows for your GC/MSD and GC only operation.
• Accurate Mass Data
  • The combination of Agilent’s proprietary quadrupole with MassWorks Software produces reproducible, highly accurate mass information, effective noise filtering, and unbiased baseline correction.
• Integrated GC-MSD Communication
  • The 7890B GC and 5977A MSD ‘talk’ continuously and form a unified system that supports the highest productivity for your laboratory.
• Sleep/Wake Mode
  • In sleep mode, you can reduce your energy costs and the system scheduler will wake the GC/MSD and ready it for your next work day.
• Programmable Helium Conservation Module
  • Reduces helium consumption for GC and GC/MS systems by changing to an alternate carrier during system stand-by.
• Safety Protection
  • If the MSD shuts down unexpectedly, GC gas flow is automatically terminated, ensuring safe operation with hydrogen and eliminates waste of costly helium.
• Parts Finder Tool
  • Quickly locate and order replacement parts for your Agilent instruments through an interactive user interface.

Agilent G413A Autoinjector

• Dual simultaneous injection saves time by doubling sample throughput
• Fast injection technology minimizes needle discrimination and sample degradation
• Perform single-stroke injection of up to 50 µL using a 100 µL syringe; multiple injections are possible depending on your needs
• Eliminate analyst-to-analyst variability and reduce rework using powerful sample preparation capabilities, including dilution, internal standard addition, heating, mixing, and solvent addition
• Modular design allows the flexibility to easily move the sampler from GC to GC or start with a single injector and add on to the system as needed

Edwards Rotary Vane Pump RV5
