Gilson Valvemate II Valve Actuator

The Gilson Valvemate II Valve Actuator automates HPLC and LC techniques to save time, extend column life and expand system capabilities. Controls high- and low-pressure, Stainless Steel or PEEK Valves to facilitate a wide range of column switching and LC applications. This amazing flexibility allows multiple valve and multiple column configurations on your Gilson systems.

Accommodates a wide range of valve configurations High-Pressure Valves:

• Analytical 2-position, 6-port, stainless steel (0.016” ID ports)
• Analytical 2-position, 10-port, stainless steel (0.016” ID ports)
• Preparative 2-position, 6-port, stainless steel (0.30” ID ports)
• Preparative 2-position, 10-port, stainless steel (0.30” ID ports)
• Preparative 2-position, 6-port, PPS (0.30” ID ports)
• Preparative 2-position, 10-port, PPS (0.30” ID ports)
• Multi-position, 6-port, stainless steel (0.016” ID ports)
• Multi-position, 10-port, PEEK (0.015” ID ports)
• Multi-position, 10-port, PEEK (0.015” ID ports)
• Multi-position, 6-port, stainless steel (0.030” ID ports)

Low-Pressure Valves:

• Multi-position, 6-port, PPS (0.030” ID ports)
• Multi-position, 6-port, PPS (0.060” ID ports)
• Multi-position, 8-port, PPS (0.060” ID ports)

Features:

• One of the smallest electronic valve actuators on the market; 9.8 x 8.3 x 15.6 x cm (3.9 x 3.3 x 6.2 in)
• Stackable; up to two VALVEMATE II modules can be stacked one on another to conserve bench space
• Valve options for solvent selection, column switching and sample trapping
• Controlled via keypad, remote contact closure or through TRILUTION® LC system software
