PAMAS SVSS-C Liquid Borne Particle Counter

PAMAS SVSS

Laboratory particle counter for aqueous fluids with precise flow control for contamination monitoring, size distribution analysis and component cleanliness control

The system PAMAS SVSS is a standard laboratory particle counter for pharmaceutical applications (control of parenterals, infusion solutions, ophtalmic & oral fluids) and other low-viscous liquids. The instrument may be used as “stand alone” or software controlled.

A stepper-motor-actuated precision syringe moves the sample through the laser-diode sensor at the optimum flow-rate and an accurate sample volume is achieved. Using interchangeable syringes, the PAMAS SVSS can analyse sampling volumes of different sizes, from 100 µl to 1000 ml. For small volumes, a special “Small Volume Kit” is available.

The system can be used with different light extinction sensors. The standard sensor PAMAS HCB-LD-50/50 is equipped with a flow-rate of 10 ml/min and a size range of 1 to 200 µm.

Product features

• Customisable measurement settings
• 16 or 32 freely adjustable size channels
• Integrated magnetic stirrer
• Use of any sample vessel
• Measuring volume of 100 µl to 1000 ml
• Automatic sample flow and volume control via a stepper motor driven syringe module
• Interchangeable syringes with 1 ml, 10 ml and 25 ml volume
