PerkinElmer Nelson 600 Series Link interface box

The Perkin Elmer / PE Nelson 600 Series LINK Interfaces are buffered, digital interface modules containing four independent RS232 ports for instrument interfacing and IEEE-488/RS232 communication ports for host communication. Each LINK module can service a single LC system or up to three independent gas chromatographs (limited to 2 model types). For GC’s, each RS232 port is capable of receiving two digital detector signals. Digital data acquired from instruments are buffered in the dynamically allocated RAM memory analogous to the Perkin Elmer NCI/900A Series Interfaces. CSA, TUV, EMI, and CE-mark certified. Each interface requires, but does not include, one IEEE or RS232 interface cable, plus the appropriate number and type of RS232 cables for supported instruments.

Features:

• Four Channel Operation
• Serial/Host Connection
• GPIB Connection
• Ethernet

This refurbished PE Nelson 600 Series Link interface box is in great condition. It has been tested at SpectraLab Scientific.

A 90 day warranty is included.
