PerkinElmer Series 200 Vacuum Degasser

Specification

Description

Channels

1-5 independent

Degassing Process

Gas permeation through a fluoropolymer membrane

Maximum Recommended Flow Rate

3.0 mL/min.

Pressure Drop

1.37 mm Hg/mL/min.

Degassing Capacity

~25% dissolved gases remaining in 60:40 MeOH/Water mixture at

1 mL/min.

Dead Volume

~480 microliters per channel for standard channel

Materials contacting solvents

PEEK, Glass-filled PTFE, Teflon AF

Power:

Power requirement if using supplied AC

Adapter

100 to 240 VAC (±10%), 1A, 50 to 60 Hz (±3 Hz)

Power Requirement if not using supplied AC

Adapter

15 to 24 VDC at 0.85 A maximum (0.5 A typical)

Wall Sockets

4 supplied with AC Adapter, interchangeable: North

America/Japan, U.K., Continental Europe, Australia

Installation Over-Voltage Category

II

Validation Output:

Signal

5 mVDC / 1 mm Hg absolute from 20 to 800 mm Hg

(0.100 VDC at 20 mm Hg; 4.000 VDC at 800 mm Hg)

Accuracy

±1.0% of reading ±0.010 VDC from 20 to 800 mm Hg

Operating Conditions:

Ambient Temperature

10 to 35 ºC

Ambient Relative Humidity (RH)

20 to 80 % RH (without condensation)

Altitude

0 to 2000 Meters

Indoor vs. Outdoor Use

Indoor

Pollution Degree

2

Storage Conditions:

Ambient temperature

-20 to +60 ºC

Ambient Relative Humidity

20 to 80% RH (without condensation)

Altitude

0 to 12000 M
