Shimadzu GCMS-QP2010 Plus and GC-2010 Plus GC-MS System with AOC-5000 Plus PAL Autosampler

System includes:

• GCMS-QP2010 Plus
• GC-2010 Plus for mass spectrometer
• AOC-5000 Plus PAL autosampler (liquid only or with headspace, other Combi PAL accessories are available)
• Rough pump
• PC with data

The GCMS-QP2010 Plus comes equipped with a variety of new features and an expanded mass range (1.5 to 1090 Daltons). Combining these attributes with two and three times the sensitivity for Octafluoronapthalene (OFN) in Electron Impact (EI) and Negative Chemical Ionization (NCI) modes respectively over the GCMS-QP2010 makes the GCMS-QP2010 Plus the ideal instrument for characterizing complex organic mixtures in fields from toxicology to environmental monitoring to food and flavors sciences.

Unmatched Sensitivity

A new and improved ion source (patent pending) features more uniform temperature control, a new filament that resists deformity, and an expanded temperature range of 100 to 300°C. These features work together to offer users world-class sensitivity for 1pg of OFN.

High-Performance Vacuum

Unlike the GCMS-QP2010 and GCMS-QP2010S, the new GCMS-QP2010 Plus employs a dual inlet Turbo Molecular Pump (TMP) that provides increased sensitivity and column flow capacity for improved performance and confident results.

Fast GCMS: FASST (Fast Automated SIM/Scan Type)

With FASST a new chapter of Fast GCMS is opened by Shimadzu. The GCMS-QP2010 Plus offers the possibility to acquire Scan as well as SIM data on one peak. Quantitation of both data sets is also possible. With a data acquisition frequency of 50 data points/second in Scan mode and up to 100 in SIM mode, data of excellent quality are obtained. This plays an important role for both quantitative and qualitative analysis as the quality of the library search is determined by the quality of the spectra.
