Shimadzu RF-1501 Spectrofluorophotometer
Item ID:
Manufacturer
Condition
3-12 month warranty
Service options & contracts available
To sell, trade-in, or service your equipment
How do we Refurbish Lab Equipment?
Looking for further assistance? Contact Us
Request Quote/ Offer
Estimate Shipping Time
Canada & U.S.: 3-5 business days
International: 5-10 business days
Tariff-Free Shipping to the U.S.!
Outstanding Sensitivity – 300 or higher signal-to-noise ratio
The unique RF-1501 optical design provides exceptional sensitivity in an incredibly compact instrument. The bright optical system and noise suppression digital filter allow for high sensitivity measurement. You get a signal-to-noise ratio greater than 300 for the Raman lines of distilled water.
The scanning speed is selectable in 4 steps, the fastest being 3,700 nm/min.
And wavelength slewing is possible at ultrahigh speeds reaching 30,000 nm/min.
Pop-in Program Packs to Meet Your Needs
In seconds, the easy-to-insert Program Packs reconfigure the RF-1501 from the standard quantitative and scanning instrument to a kinetics capable instrument, for example. You can even store your own experimental parameters on convenient Data Packs (IC RAM card).
Specifications
| Light Source | Xenon lamp, 150W, Ozone resolving type lamp housing |
| Excitation and emission monochromators | Concave, non-aberration, blazed holographic grating, F/2.4, 900 grooves/mm |
| Wavelength scale | 220 ~ 900 nm and 0 order |
| Measuring wavelength range | 220 ~ 750nm and 0 order as standard
220 ~ 900nm and 0 order optionally |
| Spectral bandwith | Choice of 10 nm and 20 nm in both excitation and emission sides |
| Wavelength accuracy | ±5 nm |
| Light source compensation | Dynode feedback system with monochromatic light monitoring function |
| Sensitivity | The S/N ratio is 300 or higher for the Raman lines of distilled water (350 nm excitation wavelength, 10 nm spectral bandwidth, and 2-second response) |
| Wavelength scanning | 4-step selection of SUPER, FAST, MEDIUM, and SLOW, (about 3,700 nm/min. at SUPER) |
| Wavelength slewing speed | About 30,000 nm/min. |
| Response | Choice of 0.02, 0.03, 0.1, 0.25, 0.5, 2, and 8 seconds for 98 % of full scale |
| Sensitivity selection | 2-step selection of HIGH and LOW (The sensitivity at HIGH is about 50 times that at LOW.) |
| Detector | Photomultiplier tube for both excitation and emission sides |
| Display | Backlit liquid crystal display, 320 X 200 dots |
| Interface | RS-232C interface, and interfaces for printer (Centronics type), autosampler, sipper, and IC card drive |
| Dimensions and weight | 500W X 400D X 255H mm, 23 kg |
| Power requirements | 100/120/220/240 V, 400 VA |
| Operational temperature range | 10 ~ 35 °C |
| Operational humidity range | 40~80 % (Below 70% with temperature higher than 30 °C.) |
