SOTAX AT Xtend 8x Dissolution Tester
Item ID:
Manufacturer
Condition
3-12 month warranty
Service options & contracts available
To sell, trade-in, or service your equipment
How do we Refurbish Lab Equipment?
Looking for further assistance? Contact Us
Request Quote/ Offer
Estimate Shipping Time
Canada & U.S.: 3-5 business days
International: 5-10 business days
Tariff-Free Shipping to the U.S.!
Whether used as a manual apparatus or as the core component in an automated dissolution system, the AT has been designed for the most demanding environments. Its unique design combines robust quality components with state-of-the-art technology to guarantee reproducible testing conditions, day after day. Depending on the required automation level, the AT can be flexibly extended with additional Xtend modules, making method transfer for increased throughput requirements easier than ever.
Specifications:
| Type | Specifications |
|---|---|
| Methods | Basket, paddle, paddle over disk, rotating cylinder, extraction cell, mini paddle, China paddle, stationary basket, intrinsic and other non-compendial methods |
| Dosage forms | Type: Tablets, sinkers, suspensions, transdermals, APIs, creams, gels, and more.
Introduction: Manual or automated (for tablets, sinkers) Inlet dimension: 15 x 30 mm |
| Bath | Opening/closing: Manual or automated
Capacity: 16.5 L Temp.range: Ambient +5°C to 55°C Control accuracy of bath temp.: +/-0.1°C No.of stirring positions: 6, 7 or 8 |
| Vessel | Type: 1 L, 2L, Mini vessel, Immersion Cell vessel, Peak vessel, China vessel
Material: 1 L, 2 L vessels: glass, polycarbonate,Teflon-coated, inactinic glass Other vessels: on demand In-vessel evaporation: <1 % per 24h at 37°C (DI water, sampling ports closed) |
| Shaft | Type: Manual or automated (HollowShaft)
Material: Stainless steel, gold-coated, Teflon-coated Stirring range: 1-250 rpm Stirring accuracy: +/-1 rpm |
| Compliance | The AT dissolution apparatus complies with all pharmacopeia requirements. |
| Tube dimensions | Inside: Ø 1.5 mmor 0.8mm
Outside: Ø 3.0 mm |
| Materials in contact with media ordosage form | PTFE tubing, glass or polycarbonate vessel, suction head in PVDF, various parts in stainless steel A316L, Viton(FPM) seals. PEEK on demand. |
| Sampling | Type: Pipette, cannula, AutoLift, HollowShaft (suction head)
Max. number of time points per off-line method (firmware): Up to 90 time points on 8 channels |
| Temperature monitoring | 1 mobile probe
Optional: individual in-vessel probes with AutoLift |
| Video monitoring (optional) | No. of channels: 6, 7 or 8
Type: Individual HD cameras with focal distance and height adjustment Position: Integrated in bath (CenterView design) Recording: Separate recording device (not controlled by the instrument) Output: Video recording and network monitoring (TCP/IP) Light: Integrated indirect light |
| Control | EasyTouch: With 5.4” color touch screen
Software: WinSOTAXplus: off-line and on-line (UV or LC) |
| Program capacity | > 100 active methods |
| Interfaces | USB, Ethernet, CAN, RS 232, D-sub |
| User Management | Unlimited users and user groups with individual access rights |
| Reporting | Print40 col, DIN A4 and US letter format through USB, LAN, RS 232 |
| Software compatibility | WinSOTAXplus |
| Noise emission | <70dB(A) |
| Environmental conditions | Temperature: 15 °C to 30°C,
Relative humidity: 10% and 75% |
| Dimensions (w x d x h) | 56 x 71 x 94 cm (1 L bath)
56 x 71 x 104 cm (2 L bath) |
