The Surveyor LC Pump Plus is a dual-piston, quaternary, low-pressure mixing pump with a built-in vacuum degasser and pulse dampener. The pumping system provides flow rates from 0.001 to 9.999 mL/min and can run precise gradients from 0.200 to 2.000 mL/min. The integral vacuum degasser offers efficient solvent degassing while requiring only 500 μL of volume, and the pulse dampener produces stable flow rates while adding only 400 μL of gradient delay volume to the system. The Surveyor LC Pump Plus is a module of the Surveyor HPLC.
Specifications
| Type | Specifications |
|---|---|
| Minimum Flow Rate | 0.001 mL/min isocratic, 0.100 mL/min gradient |
| Maximum Flow Rate | 9.999 mL/min |
| Flow Rate Accuracy | ±2% or ±2 μL/min, whichever is greater when water is pumped at 0.100 to 5.000 mL/min, 10 to 400 bar, 20 °C |
| Flow Rate Precision | ±0.3% when water is pumped at 0.100 to 5 mL/min, 10 to 400 bar, 20 °C |
| Pressure Range | 0 to 400 bar (0 to 5800 psi) |
| Operating Range | 10 to 400 bar (145 to 5800 psi) |
| Pressure Resolution | 0.01 bar (0.15 psi) |
| Solvent Capacity | Quaternary |
| Compositional Accuracy | ±1%—for binary gradient—at 1000 μL/min |
| Piston Volume | 48 μL primary piston, 24 μL secondary piston |
| Gradient Delay Volume | 785 μL |
| Degasser Type | Vacuum membrane |
| Degasser Capacity | 4 channels |
| Degasser Volume | < 500 μL per channel |
| Pulse Dampener | 400 μL |
| Wetted Parts | 316 stainless steel, PEEK, ruby, sapphire, Teflon, Hastelloy C, GFP |
| Remote Controls | Ethernet interface to the data system computer |
| Dimensions (h × w × d) | 7.1 in × 14 in × 18.5 in |
| Operating Temp | +10 °C to +40 °C |
| Storage Temp | –40 °C to +70 °C |
| Operating Humidity | 5 to 95% relative, non-condensing |
