Thermo Scientific Forma Environmental Chamber Model 3940
3-12 month warranty
Service options & contracts available
To sell, trade-in, or service your equipment
How do we Refurbish Lab Equipment?
Looking for further assistance? Contact Us
Request Quote/ Offer
Estimate Shipping Time
Canada & U.S.: 3-5 business days
International: 5-10 business days
Tariff-Free Shipping to the U.S.!
We encourage you to contact us to speak with one of our expert and professional team. Thanks for looking and we look forward to hearing from you.
Series Model Serial Number: #300501226
Perform a variety of applications with Thermo Scientific™ Forma™ environmental chambers, which can be configured for a variety of purposes and are available in multiple capacities. With a wide range of accessories and years of experience in constructing cabinets, we can construct units to match your most stringent applications.
Broad Range of Features and Controls:
- Wide temperature range of 0° to 60°C that enhances the flexibility of the unit
- Relative humidity control via steam generator from above ambient to 95% at 37°C (not available w/Cat. No. 3920)
- Sophisticated digital controls
- Programmable ramp and soak cycles for temperature and RH†
- Durable cabinets with true laminar airflow through side plenums for extremely tight uniformity
- Phenolic-coated evaporator for use in applications that create corrosive byproducts
- Manual control of defrost and refrigeration cycles
- Visible/audible safety alarms alert to over- and undertemperature conditions, deviation of humidity from set parameters (except Model 3920)
Durable Construction:
- Cold-rolled steel, powder-coated cabinet
- 2″ (5.1cm) thick, CFC-free, foamed-in-place polyurethane insulation
- Stainless-steel interior with solid stainless-steel adjustable shelves
- Directed horizontal airflow system for excellent uniformity
- Locking swivel casters for easy mobility during installation and cleaning
- Leveling feet for stability and added safety in the lab
Broad Range of Options:
- Interior lighting for Models 3920, 3940 and 3949 (Optional)
- Reinforced shelving and flooring for heavy loads
- Heatless dryer for lower humidity levels
- Access ports for probes, sensors
- Interior convenience receptacles
- CO2 (IR sensor)
- 6″ and 12″ temperature chart recorder
- Other custom options available
Compatible with:
- Recorders (197075, 198036, 198039, 198042, 201144, 201145, 201146, 201147)
- Reach-In/Environmental Chamber Solid Stainless-steel Shelf (224139)
- Reach-In/Environmental Chamber Perforated Stainless-steel Shelf (224155)
- Reinforced Stainless-steel Shelf (224161)
- Fixed Reinforced Stainless-steel Shelf for two shakers (1900005)
- Stainless-steel Door Glass Cover, factory installed (190591)
Recommended for:
Ideal for growth, stability and shelf-life testing applications
Ordering Information
† Humidity controller available on 3940/3949, 3911/3913 only
Specifications
| 29 cu. ft. | |
| 821.2 L | |
| IR Sensor | |
| Powder-coated Cold Rolled Steel | |
| 95% | |
| Environmental Chamber | |
| ±5.0% | |
| Digital, dual LED (direct set and read in % RH) | |
| Bulk polymer | |
| Water Inlet Gravity to 40psi | |
| CFC-free, R134A | |
| 0.1°C | |
| ±0.3 at 25° to 37°C | |
| 50kilohm to 1megohm resistance | |
| 38 in. | |
| 96.5 cm | |
| 88.5 in. | |
| 224.8 cm | |
| 32 in. | |
| 81.3 cm | |
| 208/220 V, 60 Hz | |
| 15 A |
| ICH, FDA, TAPPI, ASTM™ | |
| Stainless Steel | |
| No Lighting | |
| 6 supplied/19 max. | |
| 0°C to 60°C | |
| Digital Dual LED | |
| Microprocessor, PID | |
| 0.01 | |
| Steam generator; initial fill approx. 1 qt. (1L) | |
| Temperature ramp and soak, up to 24 steps | |
| ±0.1 at 25° to 37°C | |
| RTD | |
| 0.25 gal./hr. input water volume | |
| 27 x 31 x 60 in. (68.6 x 78.7 x 152.4 cm) | |
| 31 in. | |
| 78.7 cm | |
| 60 in. | |
| 152.4 cm | |
| 27 in. | |
| 68.6 cm | |
| 208/220 V | |
| 60 Hz |
