Thermo Scientific ISQ with TRACE 1300 GC-MS

For budget-mindful lab owners seeking a reliable replacement for stand-alone GC systems, the ISQ GCMS models represent robust solutions with quality design, MS operational simplicity, and proven dependability.

• Extended dynamic range detection system
• Thermo Scientific ExtractaBrite source for analytical robustness
• Mass range from 1.2 to 1100 u
• S-Shaped Ion Guide for noise reduction
• Data acquisition rates to match fast chromatography
• Full Scan/SIM simultaneous within one injection for qualitative and quantitative analysis
• Intelligent dual filament control for reliable operation

The TRACE 1300 GC is the budget-conscious investment for the basic routine laboratory looking for an intuitive single-button system, that provides ease of use with minimal instrument interaction and full data system control. It offers the same user-exchangeable, instant connect injector and detector modules and fast oven performance with exceptional retention time stability to reach an incredibly high lab productivity at reduced cost of ownership.

• Typical retention time repeatability: <0.0008 min
• Typical peak area repeatability: <0.5 % RSD
• Column oven (H × W × D): 27 × 27 × 17.7 cm; 12.9 L
• Operating temperature range: ambient +3 °C to 450 °C
• Cryogenic option minimum temperature: -100 °C with liquid nitrogen; -50 with liquid CO2
• Temperature set point resolution: 0.1 °C
• Number of ramps/plateaus: 32/33
• Maximum heating rate: 125 °C/min
• Oven cool-down (22 °C ambient): 450 °C to 50 °C in less than 4 minutes
• Ambient rejection: < 0.01 °C per 1 °C

A rough pump and PC with data system is included. Triplus autosamplers are available with the GC-MS as well.
