Thermo Scientific LTQ FT Ultra FT-MS

The Thermo Scientific LTQ FT Ultra mass spectrometer is a hybrid Fourier-Transform Ion Cyclotron Resonance (FT-ICR) featuring a novel ICR cell design, the Ultra Cell. The FT-ICR provides ultra high resolution and high mass accuracy for ions within complex samples (<1 ppm). The cell design produces enhanced sensitivity and greater dynamic range. The linear excitation characteristics of the cell allow larger cyclotron radii which significantly reduces space charge effects. These performance gains are achieved without the costs and difficulties associated with a higher field magnet.

Features :

• Automatic Gain Control— concentration independent ppb mass accuracy with space charge control
• Parallel Acquisition— high data dependent acquisition speed
• ECD and IRMPD— detailed characterization of peptides and proteins
• Fast Scan Rate with High Resolution— compatible with LC timescale
• Automated Optimization and Acquisition— simplified operation

Attomole Sensitivity

• For identification of low abundance peptides
• 50 attomole on column On-line nano-LC-MS/MS of a 5 protein mix digest (50 attomole each on column, 30 min gradient)
• Data analyzed with BioWorks 3.3
• All proteins found with at least 2 peptides, high Xcorr and high peptide probability

Mass Accuracy Over a Wider Dynamic Range

• Concentration independent mass accuracy in infusion or under LC conditions
• Detect and correctly identify low abundant co-eluting species
• Eliminates false positive identifications in bottom-up proteomics
• Unambiguous identification of unknown analytes with on-line LC-MS/MS at any concentration

Ultra-high Resolution

• Essential for the analysis of complex samples such as crude oil or Dissolved Organic Matter (DOM)

This item is pre-owned, and was in good working condition at the time it was received.
