Waters 650E Advanced Protein Purification System

This System includes:

• (1) Waters 650E Advanced Purification System
• (1) Waters 486 Tunable Absorbance Detector
• (1) Waters 600 System Controller
• (1) Water 600 Pump

Waters 486 Tunable Absorbance Detector:

• Easy to use operator interface
• Self-calibration to ensure wavelength accuracy
• Battery backup to retain parameter settings when the detector is powered down or during power interruptions
• A deuterium arc lamp
• The patented Taper-Cell flow design switch reduces refractive index interference with the absorbance signal
• Optional cells: Non-metallic, Semi-prep, Microbore, High pressure (A cell optimized for operation in LC/MS)
• Lamp shut-off to lengthen usable lamp life
• User selectable chart mark on IV integrator output (standard on 10mV)
• Wavelength scanning for determination of optimal wavelength
• Diagnostic routines to verify proper functioning
• A modular design for easy servicing

Waters 600 System Controller

• 225 L pump head volume at 45 mL/min flow rate
• 100 L pump head volume at 20 mL/min flow rate.
• Auto Blend feature can automatically blend up to four eluents in any sequence of isocratic or gradient combination for automated methods development, column cleanup, system flushing, and sample prep.

Waters 600 Pump

• Stainless steel flow path
• 50 ul pump head volume
• Maximum pressure: 5000 psi (351.5 kg/cm2)
• 0.01 to 5.0 ml/min operating flow rate
